Thermablok® Aerogel Insulation


IAPMO and SEUsing aerogel insulation technology developed by NASA, Aerogel, the highest insulating material known, is a highly efficient insulating material that breaks conductive “thermal bridging”. Adding just one thin 1/4″ by 1″ strip to only one edge of each stud in a standard wall can increase the R-value by over 32%, regardless of what insulation is in the cavity. (US Dept. of Energy, Oak Ridge and Intertek laboratory test results)

Aerogel, also referred to as “frozen smoke,” has been difficult to adapt to most uses because of its compressibility and fragility. Compressibility of an insulating material of course destroys its insulating effectiveness. The Aerogel in Thermablok material overcomes this by using a proprietary thermal process to strengthen its formula such that it is by far the least compressible of all other known aerogels. This allows it to be bent or be under great pressure while still retaining its amazing insulation properties.

Now available to the building industry, just one thin Thermablok Aerogel Insulation Strip®(pat.pend) added to the edge of each stud before adding gypsum or sheeting is all that is needed to tackle thermal bridging problems and contribute towards maximum R-value.


Thanks to its hydrophobic properties, Thermablok will not age, mold, or mildew. Thermablok uses an amorphous silica (distinctly different from crystalline silica) aerogel insulating material which is environmentally safe and recyclable.

Thermablok aerogel insulation is made up of a composite material consisting of aerogel embedded within a fiberglass type matrix.

Aerogel Thermoblok is heat and flame resistant Available in plastic encased strips (optional self-adhesive)that attach easily to the stud, Thermablok maintains its R-value over time, under a wide range of conditions. For this reason, Thermablok has made aerogel insulation available for home and commercial use.

The first video below, from the Lawrence Livermore National Laboratories, demonstrates aerogel and its properties.  The second video shows how aerogel can be used to address energy issues in the cities of tomorrow.  The third video shows how Thermablok Aerogel Insulation Strips virtually eliminate thermal bridging using a block of dry ice and a thermal camera.

Frozen Smoke VideoAerogel EcopolisThis is an example of virtually eliminating thermal bridging in construction with Thermablok Aerogel Insulation Strips (patent pending).

What is an Aerogel?

To give you an idea what makes aerogel a special material for so many uses, it is instructive to provide some structural and functional definitions.

What is a Gel?

Many chemical reactions that involve polymerization of molecules form dispersed nanoparticles in solution, particularly those that occur in three dimensions via cross-linking between growing solid chains. A gel precursor is a chemical or mixture of chemicals that can be activated toward molecular nucleation into small colloidal particles. A gel forms when a solution of these dispersed nanoparticle colloids (also called “sols”) are induced to form a semi-solid form via interparticle condensation. Sols can be stable for very long periods of time if the solution conditions are not conducive to interparticle condensation. When a catalyst is added to create the appropriate conditions for interparticle condensation, the viscosity of the solution can increase very rapidly as the semi-solid state is reached.

What is an Aerogel?

An aerogel is directly derived from a wet gel in a process that replaces the entrained liquid phase with air. If the gel is formed from a water phase, the resulting semi-solid is called a hydrogel, and the water must be exchanged with organic solvent prior to drying. If the gel is formed within an alcohol phase, the resulting semi-solid is called an alcogel, and can be dried directly. This is accomplished by increasing the temperature and pressure of the solvent phase inside of the gel structure beyond its critical point. This “supercritical” extraction condition lowers the surface tension between the liquid and the solid pore surfaces so that depressurization of the system at temperatures above the critical temperature leaves the pore structure filled with gas. A supercritical drying process avoids the tremendous pressures exerted when liquids evaporate from tiny pores. The crushing forces during evaporation are inversely proportional to the pore radii; thus a nanoporous material is easily crushed during ambient pressure drying. Some well-known chemical processing approaches chemically modify a gel surface structure to mitigate much of the damage caused by ambient pressure drying. Drying a gel at near ambient pressures is called a “xerogel” process, and produces aerogel materials that are typically denser than supercritically dried aerogel materials.
What is an Aerogel?

What are Aerogels made of?

Aerogel materials are derived from silicate materials. Aerogels represent a structural morphology (amorphous, open-celled nanofoams) rather than a particular chemical constituency. However, a great deal of study has been devoted to silica aerogels and their properties over the past 70 years. Silica aerogels were first discovered in 1931 by Kistler. His process used polymerization of silicic acid (Si(OH)4), which in turn was generated by acidic neutralization of sodium silicate in water (as seen in Equation 1).
Na2SiO3 + H2SO4 + H2O  ->  Si(OH)4 + Na2SO4     Eq.1
Using Kistler’s method, the aqueous silica hydrogels were repeatedly rinsed with volumes of fresh anhydrous methanol to remove all but trace amounts of water. Kistler brought the contents of the gel past the critical point of methanol (240°C and 1600 psi; making the solvent system “supercritical”) in a high- temperature autoclave and slowly depressurized the system at a temperature that prevented recondensation of methanol within the porous silica gel structure. This method has numerous disadvantages, particularly in the toxicity of methanol, and in the handling of a flammable solvent at very high temperatures and pressures. In the seven decades since Kistler’s seminal work, there have been significant advances made in both the use of new precursor materials, and in the removal of solvent from them. For instance, Teichner and others established in the 1960’s that silicon alkoxides (e.g. tetraethylorthosilicate or TEOS) are the preferred soluble silica source for formation of silica gels because the need for water/alcohol solvent exchange could be avoided.[2,3] Ethanol based processing using silicon ethoxide derivatives such as TEOS and polydiethylsilicate (PDEOS) have become the preferred precursors to silica aerogels over the last few decades. With these materials, water is added to liberate alcohol and silicic acid. The silicic acid is very sensitive to condensing with itself, and rapidly building sol particles. As the process continues, a three dimensional gel network is formed, filling the mold volume and entraining all of the liquid solvent. The gels can then be further strengthened and treated in an alcohol solution, avoiding the need for solvent exchange if desired. In the past 20 years, the use of supercritical carbon dioxide as a solvent for drying of gels containing organic solvent has made the process safer and more economical. Hunt pioneered the use of supercritical carbon dioxide as the solvent medium for aerogel processing [4], further reducing hazards associated with venting of superheated methanol vapor.

Aerogel Case Studies

Aerogel Thermal Insulation Case Studies

Old Mill House
Modern Energy-Saving Passive House
Aerogel Wall Insulation
44% U-Value Reduction
House Floor Insulation网调M适合在家里做的任务.熟女无套高潮内谢吼叫.阿娇
Half hour installation versus full day!
Wood Frame Insulation
Eliminates Thermal Bridging
Solar Panel Application
Thinner and better

Thermablok® Thermal Insulation Installation Suggestions

Easy Installation for Residential and Commercial Applications

Thermablok Thermal InsulationThermal Strip Insulation
Thermablok may be installed either on the exterior or interior side of the wall framing. Insulate the full length of framing members. Apply to all wall, floor or ceiling framing edges: headers, footers, trusses, window and door frames, floor joist and roof rafters.
Thermablok Thermal InsulationBlanket Insulation
Do not install Thermablok and new siding over walls that have deteriorated from moisture, insects, etc. Repair unsound walls prior to proceeding. Plan and coordinate the thermal bridging barrier insulation work to minimize the generation of off-cuts and waste.
Thermablok Instruction Guidelines

Below you can download Thermablok PDF specification/guideline documentation

Thermablok Thermal Insulation Specifications

Thermablok Physical Properties

0.40in(10mm)Thickness390F(200C)Max TempWhiteColor
9.4 lb/Ft3DensityR-Value=10.3/inchR ValueYesHydrophobic

NASA’s New Nano-Technology AEROGEL

Breakthrough Scientific Innovation now available for construction!
